Equipment List
3 Axis Vertical Machining Centers
Milltronics VM5025IL
Travel (XYZ): 50 x 25 x 24
Spindle: 35 Hp, 15,000 rpm BIG-PLUS
Features: 40 pocket ATC, Renishaw Probing
Milltronics VM4222IL
Travel (XYZ): 42 x 22 x 24
Spindle: 24 Hp, 15,000 rpm BIG-PLUS
Features: 24 pocket ATC, Coolant Through Spindle, Renishaw Probing
Milltronics VM30
Travel (XYZ): 60 x 30 x 24
Spindle: 35 Hp, 15,000 rpm
Features: 24 pocket ATC, Renishaw Probing
Milltronics VM25XL
Travel (XYZ): 60 x 25 x 24
Spindle: 35 Hp, 12,000 rpm
Features: 24 pocket ATC, Renishaw Probing
Milltronics VM25
Travel (XYZ): 50 x 25 x 24
Spindle: 30 Hp, 12,000 rpm
Features: 24 pocket ATC, Renishaw Probing
Turning Center with True C Axis and Live Tooling
Hyundai-Wia L280LM
Travel (XZ): 8.7 x 40.2
Capacity: Swing Over Bed 25.6”
Swing Over Carriage 16.3”
Max Turning Diameter 11.8”
Max Turning Length 39.4”
Spindle: 30 Hp, 3,500 rpm
Live Tooling: 4,000 rpm max, ER32, ¾” max milling, 5/8” max tap
Auxiliary Equipment
50W SFX JPT Fiber Laser
150 x 150mm Opex lens (5.90” x 5.90”)
125mm Rotary
Chevalier 618 Surface Grinder
Miller Synchrowave 250 TIG Welder
Doall 400M Horizontal Band Saw
Computer Software
Our designers utilize SolidWorks CAD software to design parts, assemblies, tooling, and fixtures for a variety of industries, ranging from aerospace to construction. This powerful design software assures accurate designs and perfect fit and function between mating components and assemblies.
At Lx3, we leverage the cutting-edge SURFCAM programming software to address our precision machining requirements. This powerful CAM package utilizes the latest techniques and cutting tool technologies to generate programs that remove material efficiently, while maintaining exceptional finish and precision.
All CAD/CAM files and project documentation are stored indefinitely on CMMC compliant servers. This maintains a secure database of valuable information for our customers benefit and internal future reference.
